Quantitative granule filling machine
Quantitative granule filling machine is a new intelligent packaging machine developed by our HondaPack, is suitable for the packaging of high-precision and fragile bulk objects, such as puffed food, potato chips, crispy rice, jelly, candy, and dried fruit, coffee bean, tea leaf, tea bag, nuts, pistachios, peanuts, beans, apple slices, dumplings, glutinous rice balls, metering packaging of seeds, and sealing process after packaging. Integrated automatic particle quantitative packaging unit.
Quantitative granule filling machine production line as below:
1. Quantitative granule filling machine:
The single-station bag packing machine is made of all stainless steel, clean and hygienic, and easy to clean. The parts in contact with the material are made of excellent 304 stainless steel, which meets the hygienic standards of food processing machinery and has food hygiene and safety. PLC controller, large screen It shows that the operation is simple and easy to learn. Through different measuring instruments, it can be applied to the packaging of liquids, sauces, granules, powders, irregular lumps and other materials. It is suitable for packaging made of multilayer composite film, single layer PE, PP and other materials. Prefabricated bags, paper bags.
Parameters of quantitative granule filling machine:
Model: C19N
Packing speed: 30 - 50 bags/min
Rated air pressure: 4-6kg
Voltage: Single phase, 220V 50/60Hz
Power: 3.7Kw
Weight: 650Kg
2. Four bucket particle quantitative scale:
The four-dou granule quantitative scale is used for weighing various granular and powdery materials, such as sugar, rice, chicken bouillon, seeds, salt, milk powder, coffee powder, seasoning powder and other materials.
1. True color 7-inch touch screen, operating system in multiple languages, and application software can be upgraded through U disk;
2. All stainless steel 304, 316 body surface material optional, IP65 dustproof and waterproof design;
3. The 3.0L adopts the stepper motor to drive the door open and close;
4. 10L adopts pneumatic door opening and closing;
5. The control system is modularized, easy to maintain and low in cost.
3. Chain bucket feeder:
The feeding machine is mainly used in conjunction with the packaging machine to reduce dust, reduce labor intensity and improve labor efficiency. Stainless steel material to meet the requirements of food.
Technical Parameters:
Conveying height: 1900mm
Machine weight: 190kg
Delivery capacity: 1.8 cubic meters per hour (adjustable)
Silo volume: 0.15 cubic meters
Power supply: Single phase, 220V 50/60Hz
Power: 600W
Dimensions: 2100 × 750 × 2350 (mm)
